CDT  Charpy Impact Tester

CDT Charpy (simple-beam) Impact Testing Machine mainly is used for determining the rigid plastics, strengthen the impact toughness of nonmetallic metarials such as nylon, glass fiber reinforced     plastic, pottery, cast stone, plastic electric apparatus, insulating metarial.  They are essential testing instruments for Quality testing section, university and college, research institution and industrial and mining enterprise. The test according to ISO179,GB/T1043, GB1834, JB/T8762, ASTM D6110, ASTM 5942 and ISO9854, etc. CDT series testing machine can be aperated easily and with 220V power supply.





ID CDT–5 CDT-15 CDT-50
Notch Type 2– 5 Joule 7,5– 15 Joule 25– 50 Joule
Prelift Angle 158˚
Pendulum Center to Sample Center Distance 385mm
Jaws Angle 30˚
Jaws Radius 2mm
Support Line Distance 40-100mm
Maximum Sample Thickness 6mm,10mm,13mm,15mm









CDT  Charpy Impact Tester

CDT Charpy (simple-beam) Impact Testing Machine mainly is used for determining the rigid plastics, strengthen the impact toughness of nonmetallic metarials such as nylon, glass fiber reinforced     plastic, pottery, cast stone, plastic electric apparatus, insulating metarial.  They are essential testing instruments for Quality testing section, university and college, research institution and industrial and mining enterprise. The test according to ISO179,GB/T1043, GB1834, JB/T8762, ASTM D6110, ASTM 5942 and ISO9854, etc. CDT series testing machine can be aperated easily and without power supply.



Standart Delivery;

Mounting Press

Brush

Funnel
Wooden Case

ID CDT–5 CDT-15 CDT-50
Notch Type 2– 5 Joule 7,5– 15 Joule 25– 50 Joule
Prelift Angle 158˚
Pendulum Center to Sample Center Distance 385mm
Jaws Angle 30˚
Jaws Radius 2mm
Support Line Distance 40-100mm
Maximum Sample Thickness 6mm,10mm,13mm,15mm











Pendulums

 JOULE  MOMENT
1 Joule  0.5155 N.m
2 Joule  1.0310 N.m
5 Joule  2.5775 N.m
7,5 Joule  3.8662 N.m
15 Joule  7,7324 N.m
25 Joule  12.8873 N.m
50 Joule  25.7747 N.m
Sample Type   Width (mm) Thickness (mm) Span mm)
Lenght (mm)
A 80±2 10±0.5 4±0.2 60
B 50±1 6±0.2 4±0.2 40
C 120±2 15±0.5 10±0.5 70
D 125±2 13±0.5 130±0.5 95

Sample Dimensions

SAMPLE TYPE DIMENSIONS
D 125 x 13 x 13 mm
C 120 x 15 x 10 mm
B 55 [50] x 6 x 4 mm
A 80 x 1 x 4 mm
